Technical Data:

Operating voltage: DC12V

Operating current: 150mA (max)

Max. transmit power: 8dBm

Rx sensitivity: -92dB

Communication frequency: 2405 - 2480MHz

Mounting height: <40ft or 12m (open environment)

Photosensitive range: 10 - 1000Lux

Operating temperature: -20 - +60℃

Max. communication distance: 100m

Dimension: 52mm(L) x 52mm(W) x 35.6mm(H)

IP rating: IP65

Weight: 35g

Features:

• Bluetooth mesh wireless network with Z10 interface

• Infrared sensor

• Photosensor, maintain constant illumiance lighting

• Bluetooth mesh control single dimming

• Magnet reset function.(magent is close to the top of the module for 5 seconds to achieve reset)

Applications:

Widely used in schools, gymnasium, warehouse, parking lot, factory, maintenance plant and other places need energy-saving/automatic control applications.
